XQ-896GL Tire Comprehensive Strength Testing Machine
I. Application Scope of Tire Comprehensive Strength Testing Machine
The tire comprehensive strength testing machine simulates various electric vehicle motors and tires, resistance, power loss and the dynamic durability of the bottom wheels and vehicle bodies during the movement under different road conditions. It provides a reliable basis for improving the quality of dynamic durability. It tests the power brought by various vehicle tires and resistance sizes and the durability performance of various electric vehicles. The price of Xingqiao Tire Comprehensive Strength Testing Machine from Guangdong Tire High-Speed Durability Testing Machine Factory is very competitive.
II. Advantages of the Tire Comprehensive Strength Testing Machine:
1.The tire comprehensive strength testing machine tests the driving performance, obstacle impact resistance performance, collision vibration resistance performance, simulated driving power performance, endurance capacity, etc.
2. For distance, power, current, speed (constant speed), the passive test can display rotational speed and battery endurance test results.
3. The tire comprehensive strength testing machine is controlled by a touch screen PLC program.
4. The distance traveled and the speed of the journey can be set and displayed.
5. The number of obstacles and their heights can be set.
6. Equipped with a micro printer for printing test data; the operation is simple and convenient.
7. A single-wheel test method is adopted, which features the motor driving the roller to move and the product driving the roller for the test.
III. Structure of the Tire Comprehensive Strength Testing Machine:
1.The main frame of the tire comprehensive strength testing machine is made of steel structure.
2. The surface is treated with high-temperature resistant enamel coating.
3. The controller is equipped with a 7-inch imported touch screen.
4. The pressure relief of the fixtures is achieved through precision cylinders.
5. Depending on the different mechanical testing methods of the foot wheels, various standard experiments can be carried out.
6. The load testing is conducted using the original mechanical weight system.
7. The installation fixture travel can be adjusted arbitrarily according to the wheel diameter of the customer's product.
IV. Main Parameters of the Tire Comprehensive Strength Testing Machine:
1.It is equipped with an external 48V 10A power supply unit, featuring temperature control, heating and temperature measurement functions.
2. Testing product size: Diameter 12 - 660mm
3. Drum diameter: According to standard
4. Wheel width: According to the standard
5. Test modes: Walking test, cruise test, power test, etc.
6. Obstacles: One set
V. Notes for the Tire Comprehensive Strength Testing Machine:
1.Before conducting the comprehensive strength test of the tires, please ensure that the power supply is correctly plugged in or connected.
2. When installing the load (weights) and the casters, make sure that the bracket is not loose in any way (such as with loose screws). If any looseness is detected, tighten it before conducting the test.
3. When the tire comprehensive strength testing machine is in operation, it is strictly prohibited to press the idler drum with your hands.
4. The mechanical transmission parts must be maintained regularly and lubricating oil must be added at regular intervals.
5. After the test is completed, it is necessary to ensure that the power supply has been turned off.
6. It is strictly prohibited to use auxiliary corrosive liquids to clean the machine. Instead, rust preventive oil must be used.
7. The tire comprehensive strength testing machine must be used exclusively by one person. The machine must not be knocked on or occupied by anyone.
8. The mechanical part of the tire comprehensive strength testing machine must be grounded.
